Problem

• The drone acts as an active protector of a sheep flock
• Threat: wolves — either rule-based (sprint + target lock) or human-controlled (multiplayer)
• Defensive action: a scarer — light cone + sound that builds wolf fear and triggers a panic flight
• The drone carries 3 HP; colliding with a wolf costs a life (1s i-frames)
• Constraints: 3-minute demo round · 5-minute training episode

→ Classic multi-agent / asymmetric-roles setup with physically realistic drone dynamics (AR-Drone 2.0 digital twin).

Pipeline Architecture

Observation & Action Space

14 observations · 4 continuous actions

Identical structure across both phases → DroneCSI.onnx is a drop-in curriculum start for phase 4.

Phase 1: DroneCSI — PPO Setup

behaviors:
  DroneCSI:
    trainer_type: ppo
    hyperparameters:
      batch_size: 512        # mini-batch per PPO update
      buffer_size: 10240     # full rollout before update (20 × batch_size)
      learning_rate: 3.0e-4
      beta: 5.0e-3           # entropy bonus → exploration
      epsilon: 0.2           # PPO clipping
      learning_rate_schedule: linear
    network_settings:
      hidden_units: 256
      num_layers: 3          # deeper MLP → richer dynamics representation
      normalize: true
    max_steps: 1_000_000
    time_horizon: 256        # length of return bootstrap


Phase 1: Curriculum Progression

Two orthogonal difficulty axes, both reward-triggered:

→ All 5 levels cleared in 150k steps · ~3 h wall time on BigOne (RTX 4090).

Phase 1: Training Results

Phase 4: Reward Shaping

Spec: "The more fear in the wolves, the more reward. Each surviving sheep is a multiplier. 5-minute episode. Penalty for sheep killed."

Reward-Hacking Prevention

Risk: the agent could learn to maximise "keep wolves afraid" via overly aggressive play — sacrificing sheep as collateral.

Mitigation:

• survivalRatio = sheepSaved / initialSheepCount
• Episode-end bonus is scaled by Lerp(0.2, 1.0, survivalRatio)
• → losing every sheep: 80% penalty on the end-bonus even if fear was high
• → saving all sheep: full reward + 1.5× multiplier

// Survival-ratio shaping: pushes agent away from
// "trade sheep for fear-spam" exploits.
AddReward(endBonus * Mathf.Lerp(0.2f, 1f, survivalRatio));
EndEpisode();


Phase 4: GAIL Imitation Learning

Pure reward shaping leaves exploration too slow → we inject human demonstrations.

reward_signals:
  extrinsic:
    gamma: 0.99
    strength: 1.0
  gail:
    strength: 0.5             # weighted against extrinsic
    gamma: 0.99
    demo_path: Assets/Demonstrations/DroneSessions/
    use_actions: true         # GAIL discriminates on (state, action)
    use_vail: false


• Demo recording: via DemonstrationRecorder, 4 Hz position logging
• Replay pipeline: existing multiplayer sessions → GAIL demos via the app.linn.games shepherd.sessions API
• Bootstrap: DroneCSI.onnx as initial policy (transfer)

Gameplay Layer 2026-05-18

Reward signals need a working game loop. Today's iteration:

Deploy Topology: Standalone (Pivot)

⚠ WebGL dropped: Unity 6 + URP = 72 GB shader variants, 3× build failures. New model: standalone clients.

No Docker Swarm needed · no GPU on u-server · training on BigOne; PPO 1M steps also fits on an 8 GB VGPU.

Multiplayer Login 2026-05-18 fix

A user-friendly login — no one needs to copy-paste CLI tokens:

1. Unity standalone button "Login with app.linn.games" → opens the system browser
2. Browser lands on /oauth/authorize?response_type=code&client_id=…&code_challenge=… (PKCE / RFC 7636)
3. If not signed in → 302 → /login, Fortify-2FA capable
4. After login → consent card "Approve / Deny"
5. Redirect to http://127.0.0.1:51742/callback?code=… via loopback (RFC 8252)
6. Unity exchanges the code for an access token, stores it in PlayerPrefs
7. MatchmakeManager flips to online mode; RevbClient connects to shepherd.{code}

→ This was a 500 error this morning — two layers fixed: the php-cli storage volume mount was missing (passport:keys vanished), and Passport 13 ships no default consent view (inline closure registered).

Live Downloads

Three platform builds currently in production, all from the shepherd-v0.3.0 release:

Auto-sync via gh workflow run "Shepherd · Upload builds from release" — new versions land on prod within a minute. JSON API: /api/shepherd/builds

Live-Demo Walkthrough

1. Grab a standalone client (see previous slide)
2. Click "Login with app.linn.games" → system browser → JWT stored in PlayerPrefs
3. Pick a role: wolf 🐺 or drone 🚁
4. Session code from backend / auto-join open session — OFFLINE mode for solo play
5. 3-minute demo round (180 s) or 5-minute training round (300 s)
6. HUD: timer · sheep status · wolf-fear bar · drone HP
7. Round end: "Drone destroyed" / "Wolf wins" / "All sheep saved" + automatic .demo upload

Drone runs DroneCSI.onnx inference in demo mode; keyboard heuristic captures GAIL demos in training mode.

Status & Roadmap

Done

✓Phase 1: DroneCSI 150k steps, 35.25 reward ✓Phase 4: reward shaping + anti-exploit ✓GAIL demo-upload API + DemoUploader.cs ✓Standalone build pipeline (Linux/Win/Mac) ✓Demo sync for training (JWT pull) ✓Multiplayer session management (Reverb WebSocket) ✓OAuth2 PKCE login (Passport 13) today ✓Gameplay layer: HP, scarer cone, wolf-hunting AI today ✓Auto-deploy via shepherd-upload-builds workflow

In Progress

⧗Phase 4 training run (1.5M steps planned) ⧗Multiplayer PvP tournament mode

Next

○Recurrent net + LSTM for longer-horizon strategies ○Integration with a real drone SDK (DJI / Autel) ○SDF heatmap in the dashboard (where the AI defends well/poorly)
